FLYLINE SOLAR ADVERTISEMENT BOARD LIGHTS

As the name suggests this system is only used to highlight advertising material which are put up in hoardings in state/national highways, street junctions, or by lanes of the street or in some roof tops of complexes. It utilizes solar as well as backup from the battery packs and it’s highly visible and attractive to catch the eye of persons watching it. It uses LED lighting system and also there is no need to convert it to ac so its cost effective and long running it can effetely control the lighting required depending on the weather conditions of that area.

FLYLINE SOLAR ADVERTISEMENT BOARD LIGHT FEATURES

►DC volt out put 12V or 24 V. ► It have automatic control system (Dusk to Down). ► It is best solution for lighting public advertising board and banners. ► It is available in 3w, 6w, 9w, 12w, 18w, 21w 24 w, 27w, 30 w, and above. ►By using powerful LED and CFL 100% brightness for the light is guaranteed.► its power consumption is very low and get very good back up. ► No need of wiring, so we can forget the headache of wiring and its expense. ► With the cost of AC cable and wiring, you can install a fly line full light system, with out electricity bill and man power. ► We can charge the battery with the help of solar cell. ► Its Initial cost is also very low. ► No further expense ► Very low maintenance. ►Its Specially designed and well developed control system to protect the whole unit.

MODELS ASSL-3 ASSL-6 ASSL-9 ASSL-12 ASSL-18
Capacity 3 WATT 6 WATT 9 WATT 12 WATT 18 WATT
Lamp / Luminary Type LED LED LED LED LED
Operating Voltage 12 V 12 V 12 V 12 V 12 V
Power Consumption 3.3 6.4 9.9 13.2 19.8
Luminary Equal to 9 W CFL 20 W CFL 30 W CFL 40 W CFL 60 W CFL
Driver technology Micro Controller Based C.C.C.V.
Lamp Efficiency 90% 90% 90% 90% 90%
Working Temp. 30° C to 50° C
Working Life 50,000 to 1,00,000 Working Hours
Operation Automatic Dusk to Down
IP Rating IP 65
Solar photovoltaic Module 10 W 20 W 50 W 70 W 100 W
Battery Voltage 12 V 12 V 12 V 12 V 12 V
Battery capacity 7 Ah 14 Ah 40 Ah 60 Ah 80 Ah
Battery Type Sealed Lead acid   Tubular
Autonomy 1/2 Days
Battery Box M.S. Box with Silver painted/ powder coated
Pole M.S. pole with Silver painted and 4 meter height
Charger Technology Micro controlled PWM Based
Warrantee ONE YEAR
