FLYLINE OFFLINE UPS

An uninterrupted power supply for minimum number of equipments is achieved through an offline UPS at an affordable price. This system turns itself on automatically whenever there is a power failure or if the voltage is low without a slight disturbance to any of the equipments.

FLYLINE OFFLINE UPS FEATURES

► Fully automatic. ► Low power consumptions. ► High voltage protection. ► Automatic voltage regulation. ► Cold start facility. ► Super fast changeover (less than 5 mille seconds). ► Low battery warning.► Single sided advanced PCB with very low component design. ► Intermittent audio indication while UPS is working. ► Intelligent Charging System for long battery life. ► Maintenance free. ► Compact in size and attractive in design. ► Built-in type and external battery models with different back-up times. ► MOSFET topology ( metal–oxide–semiconductor field-effect transistor ).

s
Offline UPS Model UPS-500 UPS-1000 UPS-1500 UPS-2000 UPS-3000
Power 750VA 1000VA 1300VA 2000VA 3000VA
Input voltage 12V 12V 24V 24V 48V
Output voltage 185V - 240V 190V - 240V 190V -240V 195V-240V 200V-240V
No load loss 1.50%
Output frequency 50 - 60Hz
Output wave Modified Sine Wave
Efficiency 95% 95% 95% 95% 95%
Battery Depending up on backup time we need
Change-over time Less than 5 mille seconds

Personal Computers, Modem, Fax Machines, Controllers, Security, Tele-communication. Available in the DLX Range of 500 VA, 750 VA,1000VA, 1300 VA 2000VA and 3000VA. Custom made Offline UPC Systems are available on demand.

Flyline Offline UPS Picture:- click here

Flyline Offline UPS Details :- click here

Electronic Products Watts Calculator :- Click Here

Flyline Solar Power Plant Installation Video of Murikens:-  Click Here

GOVT clients list of Murickens Group :-  Click Here

Flyline Solar Power Plant Working Animation :- Click Here

Murickes Brouchure :- Click Here

For quick response & order-call ( 91) 09400464444,  09447366779, 08281848484
